sDB12725 DC Blower Fans
800-356-4159
sDB12725 Series DC Blower
127x127x25MM (5" x 5" x 0.98")
| MATERIAL: | Frame: Plastic (UL94V-0) Impeller: Plastic (UL94V-0) Lead Wire: UL1007AWG#24 |
| EXPECTED LIFE: | Ball Bearing 50,000hrs (40°C) |
| TEMPERATURE RANGE: | Operating temperature -40°C~80°C (Non-condensing) Storage temperature -40°C~70°C (Non-condensing) |
| SAFETY STANDARDS: | UL, RoHS, CE |
| DC FAN SPECIALS: | RD, FG, IPXX |
Specifications
| Model No. | Rated VDC Voltage | Operating Voltage VDC | Input Current | Input Power | Speed (RPM) | Max. Air Flow CFM | Max. Air Flow m3/min | Max. Static Pressure inchH2O | Max. Static Pressure (Pa) | Noise Level (dB-A) | Weight (gram) | RFQ |
| sDB12725V12H | 12 | 7.0~13.5 | 0.60 | 7.20 | 4800 | 34.80 | 0.98 | 1.50 | 39.80 | 62.50 | 272.3 | RFQ |
| sDB12725V24H | 24 | 18.0~26.5 | 0.30 | 7.20 | 4800 | 34.80 | 0.98 | 1.50 | 39.80 | 62.50 | 272.3 | RFQ |
| sDB12725V48H | 48 | 36.0~54.0 | 0.15 | 7.20 | 4800 | 34.80 | 0.98 | 1.50 | 39.80 | 62.50 | 272.3 | RFQ |
