sD5020 Series DC Axial Fan

50x50x20MM (1.96"x1.96"x0.78")


MATERIAL:Frame: Plastic (UL94V-0)
Impeller: Plastic (UL94V-0)
Lead Wire: UL1007AWG#26 or Equivalent (+) Red, (-) Black
EXPECTED LIFE:Ball Bearing 70,000hrs (40°C)
Sleeve Bearing 30,000hrs (40°C)
TEMPERATURE RANGE:Operating temperature -10°C~70°C (Non-condensing)
Storage temperature -40°C~70°C (Non-condensing)
SAFETY STANDARDS:UL, TUV, RoHS, CE
DC FAN SPECIALS:RD, FG, IP54

Specifications

Model No.Rated VDC
Voltage
Operating
Voltage VDC
Input CurrentInput PowerSpeed (RPM)Max. Air Flow CFMMax. Air Flow m3/minMax. Static Pressure inchH2OMax. Static Pressure
(Pa)
Noise Level (dB-A)

Weight
(gram)

sD5020V5H53.5~5.50.422.10550015.560.440.2049.6231.032.0
sD5020V5M53.5~5.50.281.40500014.980.420.1742.8629.032.0
sD5020V5L53.5~5.50.201.00450013.700.390.14

34.91

26.032.0
sD5020V12U127.0~13.80.202.40650019.440.550.2972.7736.032.0
sD5020V12H127.0~13.80.182.16600017.370.490.2663.7433.032.0
sD5020V12M127.0~13.80.161.92550015.560.440.2049.6231.032.0
sD5020V12L127.0~13.80.141.68500014.980.420.1742.8629.032.0
sD5020V12D127.0~13.80.101.20450013.700.390.1434.9126.032.0
sD5020V24U2414.0~27.60.143.36650019.440.550.2972.7736.032.0
sD5020V24H2414.0~27.60.122.88600017.370.490.2663.7433.032.0
sD5020V24M2414.0~27.60.102.40550015.560.440.2049.6231.032.0
sD5020V24L2414.0~27.60.081.92500014.980.420.1742.8629.032.0
sD5020V24D2414.0~27.60.061.44450013.700.390.1434.9126.032.0
